INPUTS
Instrument Input Impedance 1M Ohm Level +4dbv Max
Effects Return Impedance 100K Ohm Level +4dbv Max
OUTPUTS
Effects Send Impedance 1K Ohm Level +4dbv Max
Speaker Out Impedance 4 or 8 Ohm
Extension Out Series Connection to Speaker Out
TUBE COMPLEMENT
Preamp (1) 12AU7, (1) 12AX7
Power (2) 6C33‐B Power Triode
OUTPUT POWER
4 or 8 Ohm Load 50 Watts RMS
*Please Note, under some circumstances, average output power may exceed 125 Watts! Peak
instant power may far exceed this rating as well! Please select speaker cabinets rated to comply
with minimum 150 watts rating or damage to speaker(s) may result!
POWER REQUIREMENTS
500 Watts at rated supply voltage of 115 Volts RMS 60 Hz
PHYSICAL PROPERTIES
Width, Depth, Height 15 ½ by 12 by 8 ½ inches
Weight 44 Lbs |
 |
 |
 |
|
