| Controls:
VOLUME: sets the output volume
DRIVE: controls the amount of overdrive.
FOCUS: Controls how easily the circuit distorts as well as adjusting overall EQ. Turning CCW gives less distortion and a mellow effect, turning CW gives a slight treble boost and earlier distortion. Good starting point is 11 o’clock.
Electrical specifications:
Supply voltage range: 7,5 to 18VDC
Current consumption at 9VDC: 5 mA
Input inpedance: 260K
Output impedance: 25K Ohm's
Complete bypass (true bypass)
